Processor | : |
Intel Xeon Processor E3-1200 v6 Family; 7th generation Intel Core i7, i5 Intel Xeon Processor E3-1200 v5 Family; 6th generation Intel® Core i7, i5Intel Turbo Boost technology; optional vPro Technology |
Operating System | : | Upto Windows 10 Pro (64-bit) |
Chipset | : | Intel C236 |
Memory | : | Up to 64GB 2133MHz Non-ECC DDR4 Memory |
Video Card | : |
AMD Radeon™ Pro WX 7100 with 8GB GDDR5 dedicated memory, AMD Radeon™ Pro WX 4150 with 4GB GDDR5 dedicated memory |
Hard Drive | : | Up to 2TB SATA hard drive (7200rpm), Up to 2TB Solid State hard drive |
Optical Drive | : | External Options Only |
Chassis | : | All-in-one constructed of CNC machined aluminum |
Side Ports | : | 1 USB 3.0 with PowerShare, 1 SD card reader, 1 Audio jack |
Back Ports | : | 4 USB 3.0, 1 HDMI-out, 1 DisplayPort 1.2, 2 Thunderbolt ™ 3, 1 Gigabit Ethernet, audio out |
Security | : | Dell Client Command Suite; Out of Band management support via vPro |
Dimensions of Non-touch desktop | : | Height: 430 mm (16.9) x Width: 613 mm (24.1) x Depth:77.5 mm (3.05) Weight: 11.3 kg (24.9 lbs) |
Dimensions of touch desktop | : | Height: 435 mm (17.1) x Width: 625 mm (24.6) x Depth: 80.2 mm (3.16) Weight: 16.9 kg (37.3 lbs) |
Slots | : | Side Ports , 1 SD-card reader |
Processor | : | Intel® Xeon® Processor E3-1200 v5 |
Operating System | : | Windows 10 Pro, Windows 7 Professional (includes Windows 10 Pro license), Linux® 7_2 (RHEL), Ubuntu® 14_04, FreeDOS |
Chipset | : | Intel® C236 Chipset |
Memory | : | Up to 64GB 2133Mhz Non-ECC DDR4 Memory, Up to 64GB 2133Mhz ECC DDR4 Memory |
Video Card | : | One PCI Express® x16 Gen 3 Graphics card up to 50W |
Hard Drive | : | Up to 4TB 5900 RPM |
Optical Drive | : | Slim-line tray load options: DVD-ROM; DVD+/-RW |
Chassis | : | Internal 3.5” bay - supports (1) 3.5” or (2) 2.5” drives; (1) external slim line optical bay |
Front Ports | : | 2 USB 2.0, 1 system ID button/LED; Internal – 1 USB 2.0 |
Power | : | 365W 90% efficient PSU (80PLUS Gold Certified Certified) Energy Star compliant;290W 85% efficient PSU (80PLUS Bronze Certified) Energy Star Compliant |
Security | : | Encryption - SED HDD (Opal FIPS), Chassis lock slot support, Lockable Port Cover, Chassis Intrusion Switch, D-Pedigree (Secure Supply Chain Functionality), Setup/BIOS Password, Optional Smart Card keyboards, Intel® Trusted Execution Technology, Intel Identity Protection Technology, Dell Secure Works, BIOS support optional Computrace5, Intel Software Guard extensions |
Dimensions | : | Height: 35.99cm (14.17”) x Width: 17.5cm (6.89”) x Depth: 43.48cm (17.12”)Weight: 9.1kg (20.06lbs) |
Slots | : | 1 Full Height PCIe x16 Gen3 ,1 Full Height PCIe x16 Gen 3 (wired x4),1 Full Height PCIe x4 Gen 3,1 Full Height PCI,1 M.2 (22x80 mm) |
Processor | : | One or two; Intel Xeon processors E5-2600 v3 family with up to eighteen cores1 per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro technology |
Operating System | : | Windows 10 Pro,Windows 7 Professional (includes Windows 10 Pro license),Linux® 7_0 (RHEL),Linux® 7_2 (RHEL),FreeDOS |
Chipset | : | Intel C612Chipset |
Memory | : | Quad channel; Up to 1TB5,1 2133 MHz DDR4 ECC RDIMM memory (32GB RDIMM); 16 DIMM slots (8/ processor 1) |
Video Card | : | Support for up to two double wide PCI Express® x16 Gen 2 or Gen 3 cards up to 675W |
Hard Drive | : | Up to 4TB 5900 RPM |
Optical Drive | : | Slim-line tray load options: DVD-ROM; DVD+/-RW |
Front Ports | : | 2 USB 2.0 |
Rear port | : | 2 USB 3.0,Serial,4 RJ45 with either NIC Option |
Security | : | Trusted Platform Module 1.2 (TPM 1.2); Intrusion switch; Setup/BIOS Password; I/O Interface Security; Kensington® lock slot, Padlock ring, Internal bezel lock; lockable power supply; Dell Data Protection (DDP): DDP | Security Tools for advanced authentication; DDP | Protected Workspace for malware; DDP | Encryption for data protection |
Dimensions | : | HxWxD: 3.41" x 17.0" x 28.37" (29.78" with bezel); 86.8mm x 434.0mm x 720.8mm (756.5mm with bezel) |
Slots | : | Up to seven PCIe Full-length Gen 3 Slots with Two CPUs in 3 riser Cards, max 2 double width x16 Cards CPU – 3 X x16 (wired as x8) Slots (default) or alternative - 1 X x16 & 1 X x16 (wired as x8) Slots |
Processor | : | Upto Intel Xeon Processor E5-2695 v4 (18C) |
Operating System | : | Upto Windows 10 Pro,Linux 7_2 (RHEL),Ubuntu 14_04,FreeDOS |
Chipset | : | Intel C612 chipset |
Memory | : | Quad channel; Up to 256GB10 2133MHz DDR4 ECC RDIMM memory |
Video Card | : | Support for two PCI Express® x16 Gen 2 or Gen 3 graphics cards up to 300W |
Hard Drive | : | Up to 4TB 5900 RPM |
Optical Drive | : | Slimline options: DVD-ROM; DVD+/-RW, Optional 13.3cm (5.25) device: DVD+/-RW; 19-in-1 media reader |
Front Ports | : | 1 USB 3.0,3 USB 2.0 |
Internal Ports | : | 1 USB 2.0,1 2x5 USB 2.0 header,4 SATA/SAS 6Gb/s,2 SATA 6GB/s for optical drives |
Rear port | : | 3 USB 2.0,3 USB 3.0,2 PS2,,Serial,1 RJ45 Intel Gigabit Ethernet |
Security | : | Dell Data Protection (DDP): DDP | Security Tools for authentication; DDP | Protected Workspace for malware; DDP | Encryption for data protection |
Dimensions | : | Mid-Tower Chassis - 16.30 x 6.79 x 18.54"; 414 x 172.6 x 471mm |
Slots | : | 5 Slots (5 Full length, 1 Half length),2 PCIe x16 Gen 3,1 PCIe x 16 Gen 3 wired x8 (Half length),1 PCIe x4 Gen 2,1 PCIe x1 Gen 2,1 PCI 32bit/33MHz |
Processor | : | Intel® Xeon® processor E5-2600 v3 family with up to fourteen cores per processor and Intel Advanced Vector Extensions |
Operating System | : | Upto Windows 10 Pro,Linux 7_2 (RHEL),Ubuntu 14_04,FreeDOS |
Chipset | : | Intel C612 chipset |
Memory | : | Quad channel; Up to 256GB7,2133 MHz DDR4 ECC RDIMM memory); DIMM slots (4/processor) |
Video Card | : | Support for two PCI Express® x16 Gen 2 or Gen 3 cards up to 300W total for graphics 825W PSU |
Hard Drive | : | Up to 4TB 5900 RPM |
Optical Drive | : | Slim-line tray load options: DVD-ROM; DVD+/-RW |
Front Ports | : | 3 USB 2.0, 1 USB 3.0, 1 Microphone, 1 Headphone, 2 RJ45 |
Internal Ports | : | 3 USB 2.0, 4 SATA/SAS 6Gb/s, 2 SATA 6GB/s (for optical drive(s)), 1 Serial |
Rear port | : | 3 USB 2.0, 3 USB 3.0, 2 PS2, 1 serial, 1 RJ45 (Intel Gigabit Ethernet) |
Security | : | lock slot, Padlock ring, Internal bezel lock; lockable power supply; Dell Data Protection (DDP): DDP | Security Tools for authentication; DDP | Protected Workspace for malware; DDP | Encryption for data protection |
Dimensions | : | HxWxD: 16.30 x 6.79 x 18.54"; 414.0 x 172.5 x 470.9mm |
Slots | : | 5 Full-length Slots,1Half length,2 PCIe x16 Gen 3,PCIe x16 Gen 3 wired x8 (Half-length),PCIe x4 Gen 2,PCIe x1 gen2,PCI 32 bit/33MHz |
Processor | : | Intel Xeon processor E5-2600 v3 family with up to eighteen cores per processor and Intel Advanced Vector Extensions |
Operating System | : | Upto Windows 10 Pro,Linux 7_2 (RHEL),Ubuntu 14_04,FreeDOS |
Chipset | : | Intel C612 chipset |
Memory | : | Quad channel; Up to 1TB8,10 2133 MHz DDR4 ECC RDIMM memory |
Video Card | : | Support for up to four8 PCI Express® x16 Gen 2 or Gen 3 cards up to 675W total for graphics |
Optical Drive | : | Slim-line tray load options: DVD-ROM; DVD+/-RW |
Front Ports | : | 1 USB 3.0,3 USB 2.0 |
Internal Ports | : | 1 USB 2.0,1 2x5 USB 2.0 header,4 SATA/SAS 6Gb/s,2 SATA 6GB/s for optical drives |
Rear port | : | 3 USB 2.0 ,3 USB 3.0 ,2 PS2,Serial,RJ45 intel Gigabit Ethernet |
Security | : | Security Tools for authentication; DDP | Protected Workspace for malware; DDP | Encryption for data protection |
Dimensions | : | HxWxD: 16.95 x 8.50 x 20.67"; 438 x 216 x 545mm |
Slots | : | 5 Slots, all Full length except Slot,2 PCIe x16 Gen 3 (plus 2 additional PCIe x16 Gen 3 with second processor Option),PCIe x16 Gen 3 wired x4 external (Slot 1),PCIe x16 Gen 2 wired x4,1 PCI 32 bit/33MHz |
